LOCATION OF PARTS - VEHICLE LEFT SIDE
1. Front wheel axle
2. Gear shift lever
3. Centre stand
4. Side stand
5. Rider foot rest L
6. Pillion foot rest L
7. Rear wheel axle
8. Saree guard
9. Wheel hugger
10. Cover frame L
1
2
2
4
5
6
7
8
9
10
3
13
KNOW YOUR TVS APACHE RTR 200 Fi4V
