2. Loosen the lock nut (2) while holding the clutch
cable adjuster (3).
3. Adjust the clutch cable adjusting nut (1) ‘in’ or ‘out’
to give sufficient play in the clutch lever.
4. After adjusting the play, hold the adjuster nut in
the same position, tighten the lock nut.
MAINTENANCE
Caution
Caution
Too much or too less clutch lever free play will
damage the clutch plates, thereby affecting the
performance of the vehicle.
Adjust the clutch lever free play only when the
engine is cold.
After adjusting free play properly, if there is a clutch
slip or there is difficulty in shifting gear, visit your TVS
Motor Company Authorised Distributor or Dealers /
Authorised Service Centers for rectification.
74
