FRONT BRAKE LEVER - ADJUSTMENT
TVS Apache RTR 200 Fi 4V comes with an adjustable
front brake lever. There are three positions provided
for you to adjust the lever to suit your palm size. The
lever can be adjusted by adjusting the "position
adjuster" (B) provided in the knob itself. Position-1 is
the closest to handle bar grip and Position-3 is the
farthest.
To adjust the lever position, push the lever forward
and rotate the "position adjuster" to any of the three
positions by aligning the 'arrow mark' on the lever to
the number provided on the adjuster.
Do not try doing any adjustment while riding as it may
lead to fatal accident.
Do not use any tool or objects to turn the "position
adjuster". Do it by hand only.
Caution
While adjusting the lever position, ensure the proper
aligning of "position adjuster" number with the arrow
mark on the lever.
Check and ensure the proper free play of both clutch
and front brake after adjusting the lever position.
Note
55
KNOW YOUR TVS APACHE RTR 200 Fi4V
