CONTROL KEY
Your TVS Apache RTR 200 Fi 4V comes with a pair of
identical control keys. These keys are to operate
ignition cum steering lock, fuel tank cap and seat lock.
IGNITION CUM STEERING LOCK
The ignition switch enables and disables the electrical
circuit and steering lock. The three positions of the
switch are described below.
1. 'OFF' position
All electrical circuits are deactivated. The key can be
removed from the lock.
2. 'ON' position
All electrical circuits are activated. The instrument
cluster and warning lights perform the self-diagnostic
cycle once upon activation. The engine can be started.
The key cannot be taken out from the lock.
3. 'LOCK' position
Your TVS Apache RTR 200 Fi 4V steering can be
locked in both 'left' and 'right' directions.
Turn the handlebar to the extreme ‘left’ or ‘right’.
Press the key in and rotate it to the ‘LOCK’ position
from OFF position. All electrical circuits are
deactivated and the steering is locked. The key can be
removed from the lock.
Insert the key into the lock and turn it to 'OFF' or 'ON'
position to unlock the steering.
When the ignition is turned ON with the engine kill switch
ON condition, priming noise of pump may be heard
which is absolutely normal.
Frequent switch 'OFF & ON' of ignition to be avoided.
After ignition key reset, there may be a delay in start of
vehicle for couple of seconds.
Note
16
KNOW YOUR TVS APACHE RTR 200 Fi4V
