LOCATION OF PARTS - VEHICLE FRONT AND REAR
FRONT
1. Turn signal lamp front L
2. Head lamp assembly
3. Oil cooler
4. Crash guard
5. Turn signal lamp front R
6. Position lamps
REAR
1. Turn signal lamp rear R
2. Reflex reflector
3. Number plate lamp
4. Turn signal lamp rear L
5. Tail lamp assembly
6. Pillion handle
2
4
3
1
5
6
1
2
4
3
5
6
