Tyco AutoPulse Z-10 - Chapter 2 Installing Cabinet and Electronics Assembly

2-1
This chapter describes removing and reinstalling the electronics assembly and surface mounting or
semi-flush mounting the cabinet to the wall.
Installing the cabinet requires the following tools and hardware:
 Phillips screwdriver
 Small, flat-blade screwdriver
 T15 Torx screwdriver (screws are slotted Torx and will accept either a T15 Torx
screwdriver or a flat-bladed screwdriver)
 Drill with appropriate bits
 Conduit shaping tools
 Conduit hole punching tool
 Conduit hardware
Refer to the page number listed in this table for information on a specific topic.
Topic See Page #
Removing/Installing the Electronics Assembly 2-2
Cutting Conduit Openings 2-3
Mounting Cabinet 2-4
Removing and Installing Plastic PCB Cover and Slide-In Labels 2-6
Chapter 2
Installing Cabinet
and Electronics Assembly
Introduction
Required Tools
and Hardware
In this Chapter
