Overview, Continued
A-7
Table 5-2. Panel Responses
Condition Panel Indications
Alarm
Red LED, corresponding to zone or SPM in alarm, pulses. Tone-Alert
sounds steady.
Trouble
Yellow LED, corresponding to zone or SPM with trouble condition, flashes.
Tone-Alert pulses. After acknowledging, the trouble LED stays ON until
the trouble condition clears.
Supervisory
Yellow Supervisory LED flashes and tone-alert sounds if a sprinkler or
waterpump valve is closed. The zone location is indicated by the blinking
yellow LED. After the ACK button is pressed, the LED for the affected
circuit will blink.
Use the ACK key to acknowledge every abnormal status present in the system (i.e., if there are
three alarms and two troubles, you must press the ACK key five times.) The panel’s tone-alert
turns off when all abnormal conditions are acknowledged.
