Tyco AutoPulse Z-10 User Manual

2-5
Semi-flush mounting involves recessing the cabinet into a wall and attaching it directly to the
wall’s studs. At a minimum, 1.5 inches of the cabinet must protrude from the wall to allow for
clearance of the panel door.
Figure 2-4. Cabinet Dimensions for Semi-Flush Mounting
14.9
DOOR
1.5" MIN
16.25
Mounting Cabinet, Continued
Semi-Flush
Mounting
