4-2
The AutoPulse Z-10 is site-programmable, using either a text-based or front-panel programming
method. In both cases, all programming selections are stored in non-volatile memory and saved
between power on/off cycles.
This section provides an overview of each programming method and identifies any prerequisite
steps (connecting serial cable, etc.) you must complete prior to programming the panel.
Notice to users, installers, authorities having jurisdiction, and other involved parties
This product incorporates field-programmable software. In order for the product to comply with
the requirements in CAN/ULC-S527, Standard for Control Units for Fire Alarm Systems, certain
programming features or options must be limited to specific values or not used at all as indicated
below.
Program feature
or option
Permitted in CAN/ULC-
S527? (Yes/No)
Possible
settings
Setting permitted in
CAN/ULC-S527
NAC Coding Yes Temporal, 20
BPM
20 BPM (Note: The
temporal setting may not
be used as this panel is for
Releasing Services only.)
The text-based panel programmer runs in a terminal emulator window on your PC and uses a
series of 11 text prompts, each of which corresponds to a major programming task, to guide you
through the programming process. Each prompt appears similar to the example shown below. The
default setting for the prompt is always designated by a d, and an asterisk (*) always indicates the
currently programmed setting. Use X to exit the programmer at any time; use C to review the
current programming configuration. When you turn the programming switch to the OFF position,
all changes you have made are saved.
To accept the currently programmed setting, simply press the Carriage Return (CR) key. To
change a setting, enter the number corresponding to your choice and then press the CR key. When
you press CR, the next prompt appears.
[01] APPLICATION MODE:
d*1 = Agent Release, Single Hazard, Cross Zoned, Combined Release
2 = Agent Release, Single Hazard, Non-Cross Zoned, Combined Release
3 = Agent Release, Dual Hazard, Cross Zoned
4 = Agent Release, Dual Hazard, Non-Cross Zoned
5 = Preaction/Deluge, Single Hazard, Cross Zoned, Combined Release
6 = Preaction/Deluge, Single Hazard, Non-Cross Zoned, Combined Release
7 = Preaction/Deluge, Dual Hazard, Cross Zoned
8 = Preaction/Deluge, Dual Hazard, Non-Cross Zoned
9 = Agent Release, Single Hazard, Cross-Zoned, NYC abort
10 = Agent Release and Preaction/Deluge, Single Hazard, Cross-Zoned,
Combined Release
11 = Agent Release and Preaction/Deluge, Single Hazard, Combined Release
12 = Agent Release, Single Hazard, Cross-Zoned, Bell/Horn/Strobe
13 = Agent Release, Single Hazard, Bell/Horn/Strobe
(d=default, *=current setting)
Select Number(X=exit):
