UNI-T UTD1000L Series User Manual

Slope Trigger
Trigger Conditions
＜, ＞,＝
Slew Rate
40pV/μs～1.6kV/μs
Measurements
Cursor
Manual
Mode
Cursor Voltage Difference(ΔV), Cursor Time Difference(ΔT),
ΔT reciprocal(Hz)(1/ΔT)
Auto Mode
Cursor allowed to display in auto mode
Auto Measurements
Peak-to-Peak, Amplitude, Max, Min,Top Point, Bottom Point,
Middle, AVG, RMS, Overshoot, Preshoot, Frequency, period,
Rise Time, Fall Time, Positive&Negative Pulse Width, Positive&
Negative Duty Cycle, Rise Delay, Fall Delay, Phase，total 22
types
Customized Parameter
Measurement
Up to 4 types at a time
Mathematics
UTD1000CL: FFT
UTD1000DL: Math and FFT
Storage
Screens: 10sets; Waveforms: 20 sets, Settings:20 types,
Waveform Recording
Store 5 sets of waveform records. UTD1000L: recording
150screens
FFT
Window
Hanning,Hamming,Biackman,Rectangular
Sample
Points
1024 points
NYQUIST
Pattern
Phase
Difference
±3degrees
Multimeter
The specified accuracy is valid over the temperature range 18 °C to 28 °C
Add 10 % of specified accuracy for each degree C below 18 °C or above 28 °C
DC Voltage:
Input Impedance : 10MΩ
Max.Input Voltage: DC400V 。
Range
Resolution
Accuracy
400.0mv
0.1mv
±(1%＋5digits）
4.000V
1mv
40.00V
10mv
400.0V
100mv
AC Voltage:
Input Impedance: 10MΩ
Max.Input Voltage: 400V AC RMS
Frequency Range: 40Hz ~ 400Hz.
Display: RMS of sinewave
Range
Resolution
Accuracy
400.0mv
0.1mv
±(1.2%＋5digits)
4.000V
1mv
UTD1000L User Manual 77
