UNI-T UTD1000L Series User Manual

40.00V
10mv
400.0V
100mv
UTD1000DL DC Current:
Max. Input DC Current: DC4A

Range
Resolution
Accuracy
999.9μA
Measure with UT-M10
(mA current module)
0.1μA
±(1.2%＋5digits)
40.00mA
Measure with UT-M10
(mA current module)
10μA
±(1%＋5digits)
400.0mA
Measure with UT-M10
(mA current module)
0.1mA
4.00A
Measure with UT-M04
(4A current divider module)
10mA
±(1.5%＋5digits)
UTD1000CL DC Current:
Max. Input DC Current: DC6A
Range
Resolution
Accuracy
350.0μA
0.1μA
±(1.2%＋5digits)
40.00mA
10μA
±(1%＋5digits)
400.0mA
0.1mA
6.00A
Measure with UT-M07
(10A current divider module)
10mA
±(1.5%＋5digits)
UTD1000DL AC Current
Max.Input AC Current: AC 4A RMS
Frequency Range: 40Hz ~ 400Hz.
Range
Resolution
Accuracy
999.9μA
Measure with UT-M10
(mA current module)
0.1μA
±(2%＋5digits)
40.00mA
Measure with UT-M10
(mA current module)
10μA
78 UTD1000L User Manual

UNI-T UTD1000L Series Specifications

General

Brand	UNI-T
Model	UTD1000L Series
Category	Test Equipment
Language	English
