89
GENERAL CARE AND MAINTENANCE
SIDE SHIFT (OPTION)
1. Shift nger bar.
2. Side shift cylinder.
This section describes only the handling of loads using the side
shift option. Before using the side shift, be sure to read this section
thoroughly and understand it. For handling (safety, operations,
inspection) of the forklift, refer to the applicable sections of this manual.
OvERvIEW OF SIDE SHIFT
Since the shift nger bar (on which the forks and the backrest are
mounted) can be shifted to the right and left only by operating the lever
from the operator's seat, you can accurately insert the fork under pallets
or stack loads correctly at targeted positions.
The following is the standard amount of side shift.
Model Variation Side Shift Distance
1H2 Series (option)
Each to right/left 100 mm (3.94 in)
Each to right/left 50 mm (2 in)
