UniPOS IFS7002 User Manual

UniPOS IFS7002 two signal loops
Instruction Manual Page 22
Revision 11/01.17 Of 145
8.3.5.1. Access Level 1
Press the button at Access Level 1 to display a screen for password entering
Enter the password using the
buttons with figures, replacing the
cursor position „_”, and the previously
entered text and the cursor itself move
one position to the right. Use buttons
and to move the cursor to
the left or to the right.
When pressed, button will
delete:
 Any figure under the cursor;
 The figure at the left of the
cursor, when no figure is
entered under it.
Password’s maximum length is 10
symbols. When a password with such
length has been already entered, no
more figures will be accepted.
Button has the following effect:
 If the password is not the correct one – the entered figures will be deleted and the cursor will
move to the first position;
 If one of the 10 passwords for Access Level 2 is entered, or a password for Access Level 3:
 The fire control panel will exit the Fire condition;
 The fire control panel will exit Information and Control Mode if it was in a combination of
Fire condition and Information and Control Mode.
To exit the screen, press buttons (Escape) or (Cancel). If the fire control panel has
been operating in a combination of Fire condition mode and Information and Control Mode, it will exit
Information and Control Mode
8.3.5.2. Access Level 2
Press button at Access Level 2 to exit Fire condition and Information and Control Mode.
8.3.6. Buttons (Move down) and (Move up)
8.3.6.1. Panel for zones in fire condition
Where suppressed messages for zones in fire condition are available they can be displayed in the
text fields of the first (upper) panel on the LCD display, by the means of buttons and situated
in the panel’s right section.
Button appears on the display where a message for a zone in Fire condition following the
message in the first text field is suppressed. Press the button to display it. When the last suppressed
text message for a zone in Fire condition is reached, the button disappears.
Button appears on the display where a message for a zone in Fire condition preceding the
message in the first text field is suppressed. Press the button to display it. When the first suppressed
text message for a zone in Fire condition is reached, the button disappears.
If a suppressed message for a zone in Fire condition is displayed, 20 s after the last button is
pressed, the message for the first zone in fire condition will be automatically restored.
Mode DAY LOC ActInp 0000 09:48:32 Mon 5 Apr 2010
FIRE CONDITION
ZONES IN FIRE:
2
1 Phase 1 Zone 001 Local
Zone 001
2 Phase 1 Zone 003 Local
Zone 003
Time Fire Phase2: 068
Time Fire Pase2: 080
PASSWORD Outputs
Enter Password: _
0
1
2
3
4
5
6
7
8
9
С
С
