UniPOS IFS7002 two signal loops
Instruction Manual Page 50
Revision 11/01.17 Of 145
The code and the specific information for events from the type General are:
Reset of the fire control panel
Menu Archive contains the following subordinate menus:
Menu Total – all records saved in the archive will be displayed (filter Total);
Menu Fire conditions – only records for fire conditions will be displayed (filter Fire);
Menu Fault conditions – only records for fault conditions will be displayed (filter Fault
conditions);
Menu Period – only records occurred during a specified period will be displayed (filter After
date, Before date or Between dates).
12.2.12.1. Menu Total
The menu displays all records of
events saved in the energy
independent memory of the fire
control panel. Filter Total is selected,
where the serial number of the event
in the filter coincides with the serial
number of the event in the archive.
Enter the menu to display the record
for the last saved event:
Buttons and on the
panel right section are seen when
more than one record is available in
the archive, and allow the user to
scroll the page to the previous or to
the next event (if available).
Using the digit buttons a random
4-digit number for the record may be
entered in the Go to field. To edit the number press button , and the last entered digit is deleted.
When you press button it displays the record having the number entered in the Go to field
If no number is entered or the number is 0, the first record (the newest one) will be selected;
If you enter a number higher than the actual number of records in the archive, the last records
(the oldest one) will be selected.
Simultaneously, the number on the Go to field disappears.
Mode:DAY LOC АctInp 0000 18:54:09 Wed 17 Маr 2010
FIRE CONTROL PANEL IFS7002
UniPOS
Archive Total Records: 0279 Go to:_
0001 Record Nо 0001 Reset
18:27:20 Wednesday 16-03-2005
