UniPOS IFS7002 User Manual

UniPOS IFS7002 two signal loops
Instruction Manual Page 51
Revision 11/01.17 Of 145
12.2.12.2. Menu Fire conditions
The menu displays only the records for events – filter Fire conditions is selected. Enter the menu
to display:
 Where no records of fire conditions are available – a screen with the text message No records
in archive, the only option is to exit the menu;
 Where records of fire
conditions are available – the
record of the first (the most
recent) event:
Buttons and on the
panel right section are seen when
more than one record for fire
condition is available in the archive,
and allow the user to scroll the page
to the previous or to the next event (if
available).
At the panel right corner the fire
counter will be displayed (the counter
can be reset only at Access Level 4).
12.2.12.3. Menu Fault conditions
The menu displays only the records for fault conditions – filter Fault conditions is selected. Enter
the menu to display:
 Where no records for fault conditions are available – a screen with the text message No
records in archive; the only option is to exit the menu;
 Where records for fault
conditions are available – the
record of the first (the most
recent) event.
Buttons and on the
panel right section are seen when
more than one record for fault
condition is available in the archive,
and allow the user to scroll the page
to the previous or to the next event (if
available).
Mode:DAY LOC АctInp 0000 19:20:19 Wed 17 Маr 2010
FIRE CONTROL PANEL IFS7002
UniPOS
Archive Fires Records: 0002 Fire counter:00001
0001 Record Nо 0191 Fire reset
17:31:47 Sunday 13-02-2005
Mode:DAY LOC АctInp 0000 19:20:19 Wed 17 Маr 2010
FIRE CONTROL PANEL IFS7002
UniPOS
Archive Faults Records: 0179
0001 Record Nо 0002 Removed Device
Zone003 Loop001 Аdrr003
Zone: Zone 003
Аddr: Point 1.003
19:24:42 Wednesday 16-03-2005
