Uponor Smatrix Base T-146
The thermostat shows the ambient, set temperature or relative
humidity on the display. Temperature settings are adjusted using the
+/- buttons on the front.
Main characteristics:
• Backlit display, dims after 10 seconds of inactivity.
• Displays Celsius or Fahrenheit.
• Calibration of displayed room temperature.
• Heating/cooling demand on display.
• Displays software version during power up sequence.
• Setpoint range is 5 – 35 °C (maximum and minimum setting may
be limited by other system settings).
• Room temperature regulation with use of optional external
temperature sensors.
• Displays optional temperature sensor values if sensors are
connected and relevant room temperature regulation is
activated.
• Switch between Comfort and ECO mode with scheduling
(requires Uponor Smatrix PULSE app).
• Adjust ECO setback value.
Components of the thermostat:
The illustration below shows the thermostat and its components.
Item Description
A Uponor Smatrix Base T-146
B Wall bracket
C Connection terminals
D Mounting material
Uponor Smatrix Base T-148
The thermostat shows the ambient, set temperature, or relative
humidity, and time on the display. Settings are adjusted using the +/-
buttons on the front. Other programmable settings are scheduling
and individual ECO mode (on a room by room basis) etc.
Uponor recommends only using this thermostat in systems without a
communication module. The scheduling function in the thermostat is
switched off in systems with a communication module.
Main characteristics:
• Backlit display, dims after 10 seconds of inactivity.
• Displays Celsius or Fahrenheit.
• Calibration of displayed room temperature.
• Heating/cooling demand on display.
• Displays software version during power up sequence.
• Setup wizard to set time and date when installed for the first time
or after a factory reset.
• 12/24h clock for scheduling.
• Internal memory to save time and date settings during short
power outages.
• Setpoint range is 5 – 35 °C (maximum and minimum setting may
be limited by other system settings).
• Room temperature regulation with use of optional external
temperature sensors.
• Displays optional temperature sensor values if sensors are
connected and relevant room temperature regulation is
activated.
• Programmable to switch between Comfort and ECO modes with
adjustable ECO setback value in the room.
• When set to a program the T-148 cannot be overridden (ECO
setback etc) by other system settings.
• Relative humidity limit alarm indicated in display (requires
communication module).
• Scheduling, pre-programmed and customizable schedules.
• Lower indoor temperature on a room by room basis with ECO
mode.
Components of the thermostat:
The illustration below shows the thermostat and its components.
Item Description
A Uponor Smatrix Base T-148
B Wall bracket
C Connection terminals
D Mounting material
Uponor Smatrix Base T-149
The thermostat shows the ambient, set temperature, or relative
humidity on the display. Temperature settings are adjusted using /
buttons on the side of the thermostat.
Main characteristics:
• Power saving e-paper display (updates every 10 minutes).
• Displays Celsius or Fahrenheit.
• Operative sensor for increased comfort.
• Calibration of displayed room temperature.
• Heating/cooling demand on display.
• Displays Uponor logo and software version during power up
sequence.
• Setpoint range is 5 – 35 °C (maximum and minimum setting may
be limited by other system settings).
• Room temperature regulation with use of optional external
temperature sensors.
• Displays optional temperature sensor values if sensors are
connected and relevant room temperature regulation is
activated.
• Switch between Comfort and ECO mode with scheduling
(requires Uponor Smatrix PULSE app).
• Adjust ECO setback value.
• Relative humidity limit alarm indicated in display (requires
communication module).
• Invert display color.
10
|
Uponor Smatrix Base PULSE
|
Installation and operation manual
