6-16 SB80 Work Platform - European
I
LLUSTRATED
P
ARTS
B
REAKDOWN
Section
6.1
C
HASSIS
A
SSEMBLY
, SB80
F
IXED
A
XLE
102008-000
ITEM PA RT NO. DESCRIPTION QTY.
1 102155-001 CHASSIS WELDMENT- FIXED AXLE 1
2 102032-000 FRONT AXLE ASSEMBLY - FIXED 1
3 102031-000 REAR AXLE ASSEMBLY 1
5 102224-000 PIN ASSEMBLY 2
7 REF. TIRE/WHL ASSY LH.(SEE FINAL ASSY) .
8 100563-000 THRUST WASHER 2 1/2 IN ID 2
9 102267-000 WHEEL NUT .875 RA 3/4-16 40
10 012002-012 FTG. 90° BULKHEAD ADAPTER 12MJ-12MJ 8
11 011732-024 SCR, HHC GR8 1-8 UNC X 3 8
12 011239-016 WASHER, 1” DIA. ASTM A-325 8
14 REF. TIRE/WHL ASSY RH (SEE FINAL ASSY) .
15 011256-010 SCREW1/2-13 UNC HHC X 1 1/4 LG 2
16 011238-008 WASHER SPLIT LOCK 1/2 2
18 011723-036 SCREW HHC 3/4-10 UNC GR8 X 4 1/2 24
19 011239-012 WASHER, 3/4 FLAT ASTM A325 48
25 102345-000 AXLE LOGIC VALVE ASSY. 1
26 102342-000 VALVE BLOCK ASSY, F RONT DRIVE CHECKS 1
27 102341-000 VALVE BLOCK ASSY, REAR DRIVE CHECKS 1
29 100385-099 HOSE GUARD (2.88 ID) FT 5
30 065369-099 HOSE GUARD (1.42 ID) FT 6
