Table 1-1: Specifications
Specifications are subject to change without notice
Meets or exceeds all applicable requirements of OSHA and ANSI A92.5-1992
ITEM SPECIFICATION
Height
Working Height, Maximum 26,2 m (86 ft.)
Platform Height, Maximum 24,4 m (80 ft.)
Platform step in height 30,5 cm (12 in.)
Up and Over Height 2,3 m (7 ft. 6 in.)
Driveable Height 24,4 m (80 ft.)
Horizontal Outreach 21,9 m (72 ft.)
Turret Rotation 360 Degrees continuous
Platform Rotation 180 Degrees
Tail Swing 99 cm (3 ft. 3 in.)
Jib Length 4,2 m (8 ft.)
Jib Arc 140 Degrees
Inside Turning Radius 3 m (10 ft.)
Outside Turning Radius 7 m (23 ft.)
Drive Speed (Lowered) 5,2 kph (3.25 mph)
Drive Speed (Elevated) 1,2 kph (0.75 mph)
Gradeability Diesel 40% Gas 35%
Controls electric Proportional
Tires 15-22.5 x 16 ply
Tires (Plus3 Option) 18-22.5 18 ply foam filled
Dimensions
Platform Size 1,8mstd(6 ft.)2,4m opt (8 ft.)
Guardrail Height 114 cm (45 in.)
Toeboards 15,2 cm (6 in.)
Maximum Platform Capacity 272 kg (600 lbs.)
Maximum Number of Occupants 2
Weight (Gasoline) 14515 kg (32,000 lbs.)
Weight (Diesel) 14741 kg (32,500 lbs.)
Overall height (stowed) 2,7 m (9 ft.)
Overall Length (stowed) 11,5 m (37 ft. 8 in.)
Overall Width (retracted) 2,4 m (8 ft.)
Overall Width (extended) 3,2 m (10 ft. 6 in.)
Overall Width (Plus3) +10 cm (+4 in.)
Wheelbase 2,9 m (9 ft. 6 in.)
Ground Clearance 28 cm (11 in.)
Power Source (Gas) GM 3.0 liter 70 H.P.
Power Source (Diesel) Perkins 1004-42 86 H.P.
System Voltage 12 VDC
Maximum Hydraulic Pressure 345 bar (5000 PSI)
