Upright SB80 - Boom Functions; Turret Rotate Functions; Jib Functions; Cage Functions

SB80 Work Platform - European 4-5
T
ROUBLESHOOTING
Section
4.3
Boom Down
Function enabled.
LED’s on DMR-30 illuminated:
BT2-05 (function enabled), BT1-08 (boom down
input), BT5-10 (boom down output to valve), BT6-06,
(dump valve output), BT7-09 (mid throttle output),
sfBT3-11 on SuperFlex (boom down output)
Boom Extend
Function enabled.
LED’s on DMR-30 illuminated:
BT2-05 (function enabled), BT1-11 (boom extend
input), BT5-12 (boom extend output to valve), BT6-06
(dump valve output), BT7-09 (mid throttle output),
sfBT3-3 on SuperFlex (boom extend output)
Boom Extend/Axle Interlock
If axles are not fully extended, the boom will not
extend.If axles are fully extended relays #5 and #6
are activated. If both relays are latched there is a 12
volt signal sent to BT4-04 on the DMR-30 and sfBT2-
10 on the SuperFlex. There will be 12 volts at TB7
and the green light (axle extend) light on the upper
controller will be illuminated.
Turret Rotate
Swing Right
Function enabled.
LED’s ON dmr-30illuminated:
BT2-05 (function enabled), BT1-09 (swing right
input), BT6-06 (dump valve output), BT7-09 (mid
throttle output), sfBT3-4 on SuperFlex (swing right
output)
Swing Left
Function enabled.
LED’s ON dmr-30 illuminated:
BT2-05 (function enabled), BT1-10 (swing left input),
BT6-06 (dump valve output), BT7-09 (mid throttle
output), sfBT3-10 on SuperFlex (swing left output)
Jib
Jib Up
Function enabled.
LED’s ON dmr-30 illuminated:
BT2-05 (function enabled), BT1-03 (jib up input),
BT5-03 (jib up output to valve), BT6-07 (boom valve
operated), BT6-06 (dump valve output), BT7-09 (mid
throttle output)
Jib Down
Function enabled.
LED’s on DMR-30 illuminated:
BT2-05 (function enabled), BT1-03 (jib down input),
BT5-04 (jib down output to valve), BT6-07 (boom
valve operated), BT6-06 (dump valve output), BT7-09
(mid throttle output)
Cage Rotate
Cage Right
Function enabled:
LED’s on DMR-30 illuminated:
BT2-05 (function enabled), BT1-05 (cage right input),
BT5-05 (cage right output to valve), BT6-07 (boom
valve operated), BT6-06, dump valve output), BT7-09
(mid throttle output)
Cage Left
Function enabled:
LED’s on DMR-30 illuminated:
BT2-05 (function enabled), BT1-06 (cage left input),
BT5-06 (cage left output to valve), BT6-07 (boom
valve operated), BT6-06, dump valve output), BT7-09
(mid throttle output)
Cage Trim Up
Function enabled:
LED’s on DMR-30 illuminated:
BT2-05 (function enabled), BT1-01 (cage trim up
input), BT5-01 (cage trim up output to valve), BT6-06
(dump valve output), BT7-09 (mid throttle output)
Cage Trim Down
Function enabled:
LED’s on DMR-30 illuminated:
BT2-05 (function enabled), BT1-02 (cage trim down
input), BT5-02 (cage trim down output to valve), BT6-
06 (dump valve output), BT7-09 (mid throttle output)
Auxilliary Power (Emergency Functions)
Both emergency Stops are pulled out (upper and
Lower)
Auxilliary Switch enabled
LED’s on DMR-30 illuminated:
BT2-04 (auxilliary function output), BT6-12 (auxiliary
pump output), Relay #1 activated (12 volts at relay
#1, terminals #5 & #8)
NOTE: If the auxilliary switch is depressed when
te engine is running the engine will stop imme-
diately.
