Upright SB80 - 2.4 Controls and Indicators

M
ACHINE
P
REPARATION
& O
PERATION
Section
2.4
2-4 SB80 Work Platform - European
2.4 C
ONTROLS AND
I
NDICATORS
The controls and indicators for operation of the SB80
Work Platform are shown in Figure 2-2. The name
and function of each control and indicator are listed
in Table 2-1. The index numbers in Figure 2-2 corre-
spond to the index numbers in Table 2-1. The opera-
tor shall know the location of each control and
indicator and have a thorough knowledge of the func-
tion and operation of each before attempting to oper-
ate the unit.
Table 2-1: Controls and Indicators
Chassis Platform
INDEX # NAME FUNCTION INDEX # NAME FUNCTION
1
Oil Pressure
Gauge
Displays current oil pressure. 17
Axle Extend/
Retract
Controls axle extend/retract functions.
2
Water
Temperature
Gauge
Displays current water temperature. 18 Lights (Optional) Turns lights on or off.
3 Hourmeter
Displays number of hours machine has been in
operation.
19
Generator
(Optional)
Charges battery for auxiliary power.
4
Emergency Stop
Switch
Cuts all power to platform and chassis controls. 20 Horn Sounds horn.
5 Key Switch Switches between chassis and platform control. 21 Emergency Stop Cuts all power to platform and chassis controls.
6 Engine Start Starts engine. 22
Axles Extended
Indicator
Indicates if axles are extended.
7
Glow Plug
(Diesel Only)
Press and hold for 20 seconds when engine is cold.
(Diesel only, below 15°f).
23
Tilt Warning
Indicator
Indicates if machine is on a slope that is unsafe.
8 Auxiliary Power
Use only in the event of power failure. Provides only
enough power to lower boom.
24
Low Oil Pressure
Indicator
Indicates if oil pressure is reaching dangerous levels.
9 Enable Switch
Must be pressed in order to control functions from the
chassis controls.
25
Torque Speed
Selector
Selects high or low speed drive.
10 Boom Control Controls boom functions. 26
Fuel Selector/
Glow Plug
Dual Fuel
: Toggles between gas/propane.
Diesel
: Hold in 20 seconds when engine is cold (below
15°f).
11
Boom Extension
Control
Controls boom extension functions. 27 Auxiliary Power
Enables auxiliary power. Provides enough power to lower
the boom in the event of a power failure.
12 Turret Control Controls turret functions. 28
Boom Raise/
Swing
Controls boom raise/lower functions vertically. Controls
turret swing horizontally.
13 Jib Control Controls jib functions. 29
Boom Extend/
Retract
Controls boom extend/retract functions.
14 Cage Rotation Controls cage rotation functions. 30 Cage Rotate Controls cage rotate functions.
15
Cage Level
Control
Levels cage if rotated. 31 Jib Raise/Lower Controls jib raise/lower functions.
16 Circuit Breaker Overcurrent protection 32 Cage Level Levels cage if out of trim.
33
Drive Control
Handle
Controls Forward or Reverse travel and steering on top.
34 Engine Start Starts engine.
35
Foot Interlock
Switch
Enables platform controls when depressed.
