SB80 Work Platform - European 1-1
Section 1
I
NTRODUCTION
& S
PECIFICATIONS
1.1 I
NTRODUCTION
Purpose
The purpose of this service and parts manual is to
provide instructions and illustrations for the operation
and maintenance of the SB80 Work Platform manu-
factured by UpRight, Inc. of Selma, California.
Scope
The manual includes procedures for proper opera-
tion, maintenance, adjustment, and repair of this
product as well as recommended maintenance
schedules and troubleshooting.
1.2 G
ENERAL
D
ESCRIPTION
The Work Platform consists of the platform, control-
ler, elevating assembly, power module, control mod-
ule, and chassis.
Platform
The platform has a non-slip aluminum floor, 1.11 m
(44 inch) high guardrails with midrail, 152 mm (6
inch) toeboards and an entrance gate at the rear of
the platform.
Platform Controller
The platform controller contains the controls to oper-
ate the machine. It is located at the front of the plat-
form. The interlock footswitch most be depressed to
operate any function from the platform. A complete
explanation of control functions can be found in Sec-
tion 2.
Elevating Assembly
The platform is raised and lowered by the boom
assembly. The hydraulic pump, driven by the engine,
powers the cylinders. Solenoid operated valves con-
trol raising and lowering.
Power Module
The power module contains the engine, hydraulic
pumps and battery.
Control Module
The Control Module contains the Hydraulic reservoir,
fuel tank, hydraulic valve manifold. volt/hour meter,
electrical terminal strips, battery, and chassis control
panel. A complete explanation of the chassis control
functions is found in Section 2.
Chassis
The chassis is a structural frame that supports all the
components of the Work Platform.
Purpose of Equipment
The objective of the Work Platform is to provide a
quickly deployable, self propelled, variable height
work platform to elevate personnel and materials to
overhead work areas.
Special Limitations
Travel with the platform raised is limited to creep
speed.
WARNING
!
!
DO NOT use the platform without guardrails
and gate properly assembled and in place.
DANGER
!
!
The elevating function shall ONLY be used
when the work platform is level and on a firm
surface. The work platform is NOT intended to
be driven over uneven, rough or soft terrain
when elevated.
