Upright SB80 - Figure 5-10: Upper Controller, Bottom Half; Figure 5-9: Upper Controller, Top Half

SB80 Work Platform - European 5-11
S
CHEMATICS
Section
5.3
Figure 5-9: Upper Controller, Top Half
Figure 5-10: Upper Controller, Bottom Half
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
17
16
1. Drive
2. Lift
3. Boom Extend
4. Emergency Stop
5. Oil Pressure
6. Tilt Indicator
7. Axle Extend Indicator
8. Torque Speed
9. Fuel Selector/Glow Plug
10. Auxilliary power
11. Cage Level
12. Jib Raise/Lower
13. Cage Rotate
14. Axle Extend
15. Horn
16. Key Switch
17. Alarm
