6-18 SB80 Work Platform - European
I
LLUSTRATED
P
ARTS
B
REAKDOWN
Section
6.1
C
HASSIS
A
SSEMBLY
, SB80
O
SCILLATING
A
XLE
102008-001
ITEM PA RT NO. DESCRIPTION QTY.
1 102155-000 CHASSIS WELDMENT-OSC AXLE 1
2 102032-001 FRONT AXLE ASSEMBLY - OSC 1
3 102031-000 REAR AXLE ASSEMBLY 1
4 102333-000 LOCK CYLINDER ASSEMBLY 2
5 102224-000 PIN ASSEMBLY 2
6 100472-012 PIN WELDMENT 4
7 REF. TIRE / WHL ASSY LH. (SEE FINAL ASSY) .
8 100563-000 THRUST WASHER 2 1/2 IN ID 4
9 102267-000 WHEEL NUT .875 RA 3/4-16 40
10 012002-012 FTG. 90° BULKHEAD ADAPTER 12MJ-12MJ 8
11 011732-024 SCR, HHC GR8 1-8 UNC X 3 4
12 011239-016 WASHER, 1” DIA. ASTM A-325 4
13 102217-000 PAD, IMPACT - FRONT AXLE 2
14 REF. TIRE / WHL ASSY RH. (SEE FINAL ASSY) .
15 011256-010 SCR, 1/2-13 UNC HHC X 1 1/4 LG 2
16 011238-008 WASHER SPLIT LOCK 1/2 2
18 011723-036 SCREW HHC 3/4-10 UNC GR8 X 4 1/2 24
19 011239-012 WASHER, 3/4 FLAT ASTM A325 48
22 011254-006 SCREW 3/8-16 UNC HHC X 3/4 LG 4
23 011238-006 WASHER SPLIT LOCK 3/8 4
25 102345-000 AXLE LOGIC VALVE ASSY. 1
26 102342-000 VALVE BLOCK ASSY, F RONT DRIVE CHECKS 1
27 102341-000 VALVE BLOCK ASSY, REAR DRIVE CHECKS 1
29 100385-099 HOSE GUARD (2.88 ID) FT 5
30 065369-099 HOSE GUARD (1.42 ID) FT 6
