Upright SB80 - Page 106

6-22 SB80 Work Platform - European
I
LLUSTRATED
P
ARTS
B
REAKDOWN
Section
6.1
B
OOM
A
SSEMBLY
,
SB80
102009-000
ITEM PA RT NO. DESCRIPTION QTY.
201 102011-000 JIB BOOM ASSEMBLY 1
202 102048-000 CARRIER TRACK ASSEMBLY 1
203 102208-000 COVER, CARRIER TRACK 1
204 102210-000 COVER, CARRIER TRACK (FRONT) 1
205 102143-000 SLIDE PAD, CARRIER TUBE 1
206 102052-000 SLIDE PAD, CARRIER TUBE 2
207 102215-000 COVER PLATE 2
208 102212-000 HOSE CLAMP, UHMW 4
209 102213-000 HOSE CLAMP, UHMW 2
210 014252-004 NUT-SERT, 1/4-20 UNC 10
211 100480-001 PIN, (1.50 DIA. X 9.88 LG.) 1
212 100480-002 PIN, (1.50 DIA. X 13.25 LG.) 1
213 011254-008 SCREW, HHC. 3/8-16 UNC X 1 2
214 011238-006 LOCKWASHER, 3/8” SPLIT RING 2
215 011254-060 SCREW, HHC. 3/8-16 UNC X 7 1/2 2
216 014996-006 WASHER, 3/8” FLAT 5
217 011248-006 LOCKNUT, 3/8-16 UNC. ESNA 5
218 011252-024 SCRE W, 1/4-20 UNC X 3 4
219 014996-004 WASHER, 1/4” FLAT 4
220 011248-004 LOCKNUT, 1/4-20 UNC, ESNA 4
221 011252-004 SCREW, HHC. 1/4-20 UNC X 1/2 14
222 011238-004 LOCKWASHER, 1/4” SPLIT RING 14
223 102380-002 FTG, 90° BULKHEAD 6MFOR-6MFOR 2
224 102380-001 FTG, 90° BULKHEAD 4MFOR-4MFOR 2
225 102109-000 STIFFENER, HOSE CLAMP 2
226 011254-024 SCREW HHC 3/8-16 UNC X 3 2
227 011254-052 SCREW HHC 3/8-16 UNC X 6 1/2 1
228 100385-099 HOSE GUARD (2.88 ID) 4 FT
