6-24 SB80 Work Platform - European
I
LLUSTRATED
P
ARTS
B
REAKDOWN
Section
6.1
C
ARRIER
T
RACK
A
SSEMBLY
,
SB80
102048-000
ITEM PA RT NO. DESCRIPTION QTY.
1 102131-000 LOWER CARRIER WELDMENT 1
2 102282-000 CARRIER TRACK 1
3 102141-000 TUBE, CARRIER (INNER) 1
4 102132-000 CARRIER TUBE WELDMENT 1
5 102138-000 ROLLER, UHMW 1
6 102136-000 SLIDE PAD, CARRIER GUIDE 1
7 102137-000 SLIDE PAD, CARRIER GUIDE 4
8 102140-000 RETAINER, SLIDE PAD 1
9 102139-000 RETAINER, SLIDE PAD 1
10 102088-000 SLIDE PAD 2
11 102389-000 CARRIER GUIDE - REAR 1
12 011254-056 SCREW, HHC. 3/8-16 UNC X 7” 3
13 011248-006 LOCKNUT, 3/8-16 UNC ESNA 3
14 011828-008 SCR, FLT HD SOC 1/4-20 UNC X 1 4
15 011248-004 LOCKNUT, 1/4-20 UNC ESNA 6
16 102053-000 SLIDE PAD 1
17 014024-006 SCREW, BUTTON HD SOC 3/8-16 X 3/4 2
19 011821-006 SCR, BUTT.HD.SOC.1/4-20 UNC X 3/4 10
20 014996-004 WASHER, 1/4” FLAT 6
21 100631-000 SLIDE PAD UPPER 2
