6-26 SB80 Work Platform - European
I
LLUSTRATED
P
ARTS
B
REAKDOWN
Section
6.1
B
OOM
E
XTEND
A
SSEMBLY
SB80
102049-000
ITEM PA RT NO. DESCRIPTION QTY.
1 102253-000 EXTENSION CYL. 1
2 102146-000 ROD SLIDE WELDMENT, LOWER 1
3 102149-000 CYL. SLIDE WELDMENT 1
4 102118-000 ROD SLIDE WELDMENT, UPPER 1
5 102082-000 ROD SLIDE (UHMW) 8
6 102088-000 PAD, ROD SLIDE (UHMW) 18
7 100631-000 PAD, UHMW 4
8 102089-000 SPACER 8
9 011252-052 SCREW, HHC. 1/4-20 UNC X 6 1/2 8
10 014996-004 WASHER, 1/4” FLAT 16
11 011248-004 LOCKNUT, 1/4-20 UNC ESNA 8
12 011254-022 SCREW, HHC. 3/8-16 UNC X 2 3/4 8
13 014996-006 WASHER, 3/8” FLAT SAE 16
14 011248-006 LOCKNUT, 3/8-16 UNC ESNA 8
15 011828-006 SCR, FLT HD. SOC. 1/4-20 UNC X 3/4 48
16 011254-010 SCREW, HHC. 3/8-16 UNC X 1 1/4 4
17 011238-006 LOCKWASHER, 3/8” SPLIT RING 4
18 100434-008 FITTING, 90° ADAPTER 6MB-6MFOR 2
19 100432-009 FITTING, STR ADAPTER 6MB-6MFOR 2
20 011828-003 SCR, FLT HD. SOC. 1/4-20 UNC X 3/8 16
21 100621-000 SLIDE PAD 2
