6-28 SB80 Work Platform - European
I
LLUSTRATED
P
ARTS
B
REAKDOWN
Section
6.1
J
IB
A
SSEMBLY
,
SB80
102011-000
ITEM PA RT NO. DESCRIPTION QTY.
1 100456-001 UPPER JIB WELDMENT SB80 1
2 100458-000 LOWER JIB WELDMENT 1
3 102062-000 BELLCRANK WELDMENT 1
4 102339-000 JIB CYLINDER ASSEMBLY 1
5 102340-000 ROTARY ACTUATOR ASSY 1
6 102205-000 CAGE TRANSITION WELDMENT 1
7 100472-007 WELDMENT, PIN 4
8 100484-001 WELDMENT, ROTATOR PIN 1
9 011248-010 LOCKNUT, 3/4-10 UNC ESNA 1
10 100562-150 BEARING 8
11 100472-008 WELDMENT, PIN 1
12 011240-012 WASHER, Ø 3/4” FLAT 1
13 011248-012 LOCKNUT, 3/4-10 UNC ESNA 1
14 011254-004 SCR, HHC 3/8-16 UNC X 1/2 8
15 011238-006 LOCKWASHER, Ø 3/8 SPLIT RING 8
16 011256-010 SCR, HHC. 1/2-13 UNC X 1 1/4 6
17 011238-008 LOCKWASHER, Ø 1/2 SPLIT RING 6
19 102332-000 VALVE BLOCK ASSY. 1
21 011252-006 SCREW, HHC. 1/4-20 UNC X 3/4 2
22 011238-004 LOCKWASHER, 1/4” DIA. 2
23 061692-099 3/16 GROMMET FT 1.5
24 013919-012 CLAMP HOSE KMC COV 2113 3
25 100692-000 COVER, JIB BOOM 1
30 011248-004 LOCKNUT, 1/4-20 UNC ESNA 5
31 011240-004 WASHER 1/4 FLAT 5
To Next Page
