6-30 SB80 Work Platform - European
I
LLUSTRATED
P
ARTS
B
REAKDOWN
Section
6.1
T
URRET
A
SSEMBLY
,
SB80
102010-000
ITEM PA RT NO. DESCRIPTION QTY.
1 102100-001 TURRET WELDMENT, MACHINED 1
2 102038-000 ROTARY MANIFOLD ASSY. 1
3 102346-000 SWING DRIVE 1
4 102270-000 SWING DRIVE MOTOR 1
5 100267-001 MOUNTING BRACKET, VALVE BLOCK 2
6 102039-000 VALVE BLOCK ASSY 1
7 100360-000 MOUNTING BRACKET WELDMENT 1
8 100365-001 MOUNTING BRACKET WELDMENT 1
9 100356-000 PIVOT WELDMENT 2
10 100374-002 GUARD PANEL 1
11 100376-000 GUARD PANEL 1
12 100371-000 GUARD PANEL 1
13 100373-000 GUARD PANEL 1
14 102112-000 LATCH BRACKET WELDMENT 1
15 102112-001 LATCH BRACKET WELDMENT 1
16 102220-000 SLEW LOCK WELDMENT 1
17 100278-001 PIN, SLEW LOCK 1
18 063783-007 LANYARD ASSY 1
19 100595-000 LOCKING PIN 1
20 011297-010 5/8” DIA. BELLVILLE CONICAL WASHER 14
21 011273-010 NUT, HEX JAM 5/8-11 UNC 4
22 011248-008 LOCKNUT, 1/2-13 UNC. ESNA 3
23 011291-022 SCR (GR 8) HHC. 5/8-11 UNC X 2 3/4 16
27 011256-010 SCREW, HHC. 1/2-13 UNC X 1 1/4 1
28 011254-012 SCREW, HHC. 3/8-16 UNC X 1 1/2 20
29 014996-006 WASHER, 3/8” FLAT STEEL 32
30 011248-006 LOCKNUT, 3/8-16 UNC ESNA 2
31 011256-032 SCREW, HHC. 1/2-13 UNC X 4” LG. 3
32 011240-005 WASHER, 5/16” FLAT STEEL 4
33 011238-005 LOCKWASHER, 5/16” SPLIT RING 4
34 011253-006 SCREW, HHC. 5/16-18 UNC X 3/4 LG. 4
35 011238-006 LOCKWASHER, 3/8” SPLIT RING 32
36 011254-008 SCREW, HHC. 3/8-16 UNC X 1 30
37 102343-000 SLEW MOTOR VALVE BLOCK ASSY. 1
38 102261-000 SWING BE ARING 1
39 011239-012 WASHER, F LAT ASTM A-325 3/4” 24
40 011723-028 SCREW,HHC.(GR.8) 3/4-10 UNC X 3 1/2 24
42 011238-008 LOCKWASHER, 1/2” SPLIT RING 2
43 011746-008 DOWEL PIN, 1/2 DIA X 1” LG 3
44 014334-014 SCREW, SHC. 5/16-18 UNC X 1 3/4 4
45 102360-000 REAR COVER 1
46 011256-014 SCREW, HHC. 1/2-13 UNC X 1 3/4 2
47 102365-000 MOUNTING PLATE, SWING LOCK 1
48 102395-000 PLATE, ROTARY MANIFOLD STOP 1
49 100242-011 GASKET, SWING DRIVE 1
ITEM PA RT NO. DESCRIPTION QTY.
