6-32 SB80 Work Platform - European
I
LLUSTRATED
P
ARTS
B
REAKDOWN
Section
6.1
C
OVER
A
SSEMBLY
,
SB80
102046-000
ITEM PA RT NO. DESCRIPTION QTY.
1 100130-001 COVER, TURRET LEFT 1
2 100131-000 COVER, TURRET RIGHT 1
3 100368-000 BEARING, HINGE 4
4 100126-000 GAS SPRING 4
5 100127-000 LATCH, COVER 4
6 100128-000 BUMPER, RUBBER 4
7 100119-000 BALL STUD 13MM - WITH SAFETY CLIP 8
8 100144-000 EXHAUST PIPE WELDMENT 1
9 100350-001 COVER RIB WELDMENT 1
10 100353-000 COVER RIB WELDMENT 1
11 100370-099 DOOR SEAL “C” FT 12
12 100383-099 DOOR SEAL “B” FT 6
13 11273-006 NUT 3/8 JAM 8
14 11253-018 SCREW, HHC. 5/16-18 UNC X 2 1/4 4
15 14996-005 WASHER 5/16 SAE FLAT 16
16 11248-005 NUT 5/16-18 ESNA 4
17 11252-006 SCREW HHC 1/4-20 UNC X 3/4 LG 16
18 11248-004 NUT 1/4 ESNA 38
19 14996-004 WASHER 1/4 SAE FLAT 36
20 11252-008 SCREW HHC 1/4-20 UNC X 1 LG 22
21 11238-005 WASHER 5/16 LOCK 8
23 11240-004 WASHER 1/4 FLAT 12
