Upright SB80 - Engine Module Assembly, SB80, Diesel

6-34 SB80 Work Platform - European
I
LLUSTRATED
P
ARTS
B
REAKDOWN
Section
6.1
E
NGINE
M
ODULE
A
SSEMBLY
,
SB80, D
IESEL
102012-000
ITEM PA RT NO. DESCRIPTION QTY.
1 102283-000 ENGINE, PERKINS DIESEL 1
2 100168-001 ENGINE MODULE WELDMENT 1
3 102325-000 DRIVE PUMP ASSEMBLY 1
4 102326-000 LIFT PUMP ASSEMBLY 1
6 102291-000 OIL COOLER (INCL. MTG KIT) 1
7 100562-150 BUSHING, GARLOCK 1 1/2 X 2 2
8 100210-000 BATTERY TRAY WELDMENT 1
9 62299-006 BATTERY, 12 VOLT 1
10 102331-000 VALVE BLOCK ASSY, BRAKE, AXLE LOCK, 2-SPEED 1
11 102378-000 OIL COOLER MOUNTING BRACKET 2
12 102327-000 FILTER ASSEMBLY 1
13 100209-002 ENGINE MOUNT, ISOLATOR 4
18 068132-001 RELAY 2
19 011922-006 FITTING, STR. ADAPTER 6MP-8FP 1
20 100332-000 SENDING UNIT, WATER TEMP 1
21 063947-005 NUT, 5MM 1
22 100324-000 POWER CONVERTER 1
23 100318-000 MOUNTING BRACKET 1
24 013888-012 O-RING, PARKER #2-152 1
25 011246-004 NUT, 1/4-20 UNC THIN ESNA 6
26 013487-001 FITTING, STR. ADAPTER 2MP-2MP 1
27 011915-001 FITTING, TEE ADAPTOR 2F P-2FP-2FP 1
28 068954-001 OIL PRESSURE SWITCH 1
29 100333-000 OIL PRESSURE SENDING UNIT 1
30 011238-006 LOCKWASHER, 3/8” SPLIT RING 2
31 011254-008 SCREW, HHC. 3/8-16 UNC. X 1 2
32 014996-008 WASHER, 1/2” FLAT 2
33 011238-008 LOCKWASHER, 1/2” SPLIT RING 2
34 011256-012 SCREW, HHC. 1/2-13 UNC. X 1 1/2 2
35 011252-008 SCREW, HHC. 1/4-20 UNC X 1 2
36 014996-004 WASHER, 1/4” FLAT 2
37 011248-004 LOCKNUT, 1/4-20 UNC ESNA 2
38 011252-024 SCREW, HHC. 1/4-20 UNC. X 3 6
39 011248-005 LOCKNUT, 5/16-18 UNC. ESNA 4
40 011252-004 SCREW, HHC. 1/4-20 UNC X 1/2 6
41 011252-006 SCREW, HHC. 1/4-20 X 3/4 8
42 011238-004 LOCKWASHER, 1/4” SPLIT RING 2
43 011254-024 SCREW, HHC. 3/8-16 UNC X 3 1/2 4
44 011248-006 LOCKNUT, 3/8-16 UNC ESNA 16
45 063082-000 J-BOLT, BATTERY HOLD-DOWN 2
46 064040-001 BATTERY HOLD-DOWN BAR 1
47 011252-022 SCREW, HHC. 1/4-20 UNC X 2 3/4 2
48 011254-006 SCREW, HHC. 3/8-16 UNC X 3/4 8
49 011253-007 SCREW, HHC. 5/16-18 UNC X 7/8 4
51 011847-004 CLEVIS (WITH PIN AND KOTTER) REF
52 016776-007 THREADED ROD, 1/4-28 UNF X 7 1/2” LG REF
53 102369-000 THROTTLE LINKAGE REF
54 020495-004 HEX JAM NUT, 1/4-28 UNF REF
ITEM PA RT NO. DESCRIPTION QTY.
