Upright SB80 - Page 120

To Next Page

To Previous Page

6-36 SB80 Work Platform - European

LLUSTRATED

ARTS

REAKDOWN

Section

6.1

NGINE

ODULE

SSEMBLY

SB80, D

IESEL

102012-000

ITEM PA RT NO. DESCRIPTION QTY.

201 102022-000 WIRE HARNESS 1

202 068760-000 PLUG, CONNECTOR 1

203 068760-001 RECEPTACLE, CONNECTOR 2

204 068761-000 LOCK WEDGE, PLUG 1

205 068661-001 LOCK WEDGE, RECEPTACLE 1

206 068762-000 PIN, CONTACT 11

207 068762-001 SOCKET, CONTACT 8

208 068764-000 PLUG, SEALING 12-14 GA. 1

209 029617-002 CONN. MALE .25 INSUL. 14-16 GA. 6

210 064195-032 BATTERY CABLE ASSY. 32” LG. 1

211 064195-050 BATTERY CABLE ASSY. 50” LG. 1

212 064195-065 BATTERY CABLE ASSY. 65” LG. 1

213 068908-000 BOOT, DEUTSCH #DT-12-S-BT 1

214 068908-001 BOOT, DEUTSCH #DT-12-P-BT 1

215 014435-001 BATTERY TERMINAL ADAPTER 2
