6-38 SB80 Work Platform - European
I
LLUSTRATED
P
ARTS
B
REAKDOWN
Section
6.1
C
ONTROL
M
ODULE
A
SSEMBLY
,
SB80, D
IESEL
102014-001
ITEM PA RT NO. DESCRIPTION QTY.
1 100176-001 CONTROL MODULE TRAY WELDMENT 1
2 102041-000 FUEL TANK ASSY (GAS) 1
3 100274-000 TANK STRAP 2
4 102042-000 HYDRAULIC RESERVOIR ASSY 1
5 064040-000 BATTERY HOLD DOWN 1
6 062299-002 BATTERY AUX 12V 1
7 102334-000 POWER UNIT (EMERGENCY LOWERING) 1
8 102241-000 STRAPPING EDGE PROTECTOR 4
11 029945-018 LEVEL SENSOR (GAS & DSL DOM) REF
12 102018-000 LOWER CONTROL BOX ASSY (DSL) REF
13 100210-000 WELDMENT, BATTERY TRAY 1
14 100313-000 TANK TAB 1
15 011252-008 SCREW, HHC. 1/4-20 UNC X 1 10
16 014996-004 WASHER 1/4 SAE FLAT PLTD 16
17 011248-004 NUT HEX ESNA 1/4-20 UNC 12
18 011253-012 SCREW HHC GR5 5/16-18 UNC X 1 1/4 2
19 014996-005 WASHER 5/16 SAE FLAT PLTD 4
20 011248-005 NUT, HEX ESNA 5/16-18 UNC 2
21 011240-006 WASHER, STD FLAT 3/8 4
22 011248-006 NUT HEX ESNA 3/8-16 UNC 2
23 011253-007 SCREW HHC 5/16-18 UNC X 7/8 8
24 012039-000 J-BOLT 2
25 011254-006 SCREW HHC GR5 3/8-16 UNC X 3/4 2
26 064195-009 BATTERY CABLE ASSY X 9” (5/16 X 5/16) 1
27 062125-011 BATTERY CABLE ASSY X 9” (3/8 X 5/16) 1
28 062125-016 BATTERY CABLE ASSY X 16” (3/8 X 5/16) 1
29 010154-000 COVER, BATTERY TERMINAL 2
30 102386-002 FTG. STR. BULKHEAD 4MP-4MJ 1
31 011915-002 FTG, TEE 1/4 FEMALE PIPE 1
32 102299-000 PRESSURE SWITCH 2
33 010147-001 LOCKNUT, BULKHEAD FTG. 1
34 014435-001 BATTERY TERMINAL ADAPTER 2
