6-40 SB80 Work Platform - European
I
LLUSTRATED
P
ARTS
B
REAKDOWN
Section
6.1
U
PPER
C
ONTROLLER
A
SSEMBLY
,
SB80, D
IESEL
102016-001
ITEM PA RT NO. DESCRIPTION QTY.
1 100325-000 DRIVE CONTROLLER 1
2 100326-000 LIFT CONTROLLERER 1
3 100327-000 EXTEND CONTROLLER 1
4 100309-001 UPPER CONTROL BOX 1
5 100310-000 STIFFENER, UPPER CONROLLER 1
6 012797-000 SWITCH TOGGLE SPST MAINTAINED 1
7 012798-000 SWITCH TOGGLE SPDT MOMENTARY 4
8 102294-001 INDICATOR LIGHT, RED 1
9 102294-002 INDICATOR LIGHT, AMBER 1
10 102294-004 INDICATOR LIGHT, GREEN 1
12 064446-003 EMERGENCY STOP BUTTON 1
13 064443-002 CONTACT BLOCK N.C. 3
14 064417-001 FLANGE MOUNT 2
15 012798-005 SWITCH TOGGLE DPST MOMENTARY 1
16 067654-000 PUSH BUTTON, FLUSH (BLACK) 1
17 064443-001 CONTACT BLOCK N.O. 1
18 012798-006 TOGGLE SWITCH 1
