Upright SB80 - Page 134

6-50 SB80 Work Platform - European
I
LLUSTRATED
P
ARTS
B
REAKDOWN
Section
6.1
F
RONT
A
XLE
A
SSEMBLY
,
SB80, O
SCILLATING
A
XLE
102032-001
ITEM PA RT NO. DESCRIPTION QTY.
1 102171-001 FRT AXLE WELDMENT (OSCILATING) 1
2 102166-000 INNER EXT. TUBE WELDMENT (L.H.) 1
3 102166-001 INNER EXT. TUBE WELDMENT (R.H.) 1
4 102163-000 STEERING KNUCKLE WELDMENT (L.H.) 1
5 102163-001 STEERING KNUCKLE WELDMENT (R.H.) 1
6 100564-000 THRUST WASHER 2
7 102258-000 WHEEL DRIVE, AUBURN 8B 2
8 102329-000 ASSY FRONT DRIVE MOTOR 2
9 102344-000 STEERING CYLINDER ASSY. 2
10 102168-001 WEAR PAD (NON-THREADED) - BLUE 4
11 102168-000 WEAR PAD, (THREADED) - BLUE 4
12 102178-000 STOP BLOCK, THREADED 2
13 100575-013 ANCHOR PIN, STEERING CYL. 2
14 100086-000 KING PIN WELDMENT LOWER 2
15 100472-011 PIN WELDMENT 2
16 102335-000 AXLE EXTEND CYLINDER ASSY. 1
17 068899-001 BUSHING, 2” I.D. X 1.5” LG. 4
18 011848-050 CLEVIS PIN, 1” DIA X 2.75 LG. 2
19 062889-002 CLIP, .177 DIA WIRE 2
20 102234-000 SHIM, 20 GA. AS REQ’D.
21 011238-006 LOCKWASHER, 3/8” SPLIT RING 48
22 011254-012 SCREW, HHC. 3/8-16 UNC X 1 1/2 LG. 6
23 011254-006 SCREW, HHC. 3/8-16 UNC X 3/4 LG. 2
24 065214-000 PIN RETAINER 2
25 100562-250 BUSHING, 2.5 I.D. GARMAX GM4048-40 2
26 011238-008 LOCKWASHER, 1/2” SPLIT RING 12
27 011256-008 SCREW, HHC. 1/2-13 UNC X 1” LG. 8
28 011239-010 WASHER 5/8 FLAT ASTM 16
29 011291-014 SCREW, HHC GR8 5/8-11 UNC X 1 3/4 16
30 011239-008 WASHER 1/2 FLAT ASTM 4
31 011238-008 WASHER 1/2 SPLIT LOCK 4
32 014033-012 SCREW HHC GR8 1/2-13 UNC X 1 1/2 4
33 0- O-RING 2
34 0- GASKET 2
35 011254-012 SCREW HHC 3/8-16 UNC X 1 1/2 2
37 102234-001 SHIM, 20 GA. (BENT) AS REQ’D.
38 102371-000 KING PIN WELDMENT UPPER 2
39 011254-007 SCREW, HHC 3/8-16 UNC X 7/8 LG 32
40 011248-006 NUT 3/8-16 UNC ESNA 2
41 102168-003 WEAR PAD (NON-THREADE D) - YELLOW 4
42 102168-002 WEAR PAD, (THREADED) - YELLOW 4
43 102249-000 AXLE EXTENSION INDICATOR STRIP 6
44 065368-001 TACK FASTENER 24
