6-52 SB80 Work Platform - European
I
LLUSTRATED
P
ARTS
B
REAKDOWN
Section
6.1
R
EAR
A
XLE
A
SSEMBLY
,
SB80
102031-000
ITEM PA RT NO. DESCRIPTION QTY.
1 102174-000 OUTER AXLE REAR WELDMENT 1
2 102159-000 REAR INNER AXLE TUBE ASSY L.H. 1
3 102335-000 AXLE EXTEND CYLINDER ASSEMBLY 1
4 102330-000 REAR DRIVE MOTOR ASSY 2
5 102258-000 AUBURN 8B WHEEL DRIVE 2
6 102279-000 AUSCO 76260 SAE B BRAKE 2
7 102159-001 REAR INNER AXLE TUBE ASSY R.H. 1
8 102178-000. THREADE D THIN STOP BLOCK 2
9 102168-000 WEAR PAD (THREADED) - BLUE 4
10 102168-001 WEAR PAD (NON THREADED) - BLUE 4
11 102176-000 COVE R PLATE REAR AXLE 4
12 011848-050 PIN CYLINDER MOUNT 1 DIA X 2 3/4 LG 2
13 062889-012 HAIR PIN .177 DIA X 3 3/4 LG 2
14 102234-000 SHIM 20GA 8
15 011291-014 SCREW HHC GR8 5/8-11 UNC X 1 3/4 16
16 011240-006 WASHER 3/8 FLAT 32
17 011254-008 SCREW HHC 3/8-16 UNC X 1 32
18 011238-006 WASHER 3/8 SPLIT LOCK 32
19 011256-008 SCREW HHC 1/2-13 UNC X 1 8
20 011238-008 WASHER 1/2 SPLIT LOCK 8
21 102234-000 SHIM 20GA (BENT) 8
22 102168-002 WEAR PAD (THREADED) - YELLOW 4
23 102168-003 WEAR PAD (NON THREADED) - YELLOW 4
24 100434-002 FITTING 90° 4MB-4MFOR 2
26 011256-040 SCREW HHC 1/2-13 UNC X 5 4
27 011240-008 WASHER 1/2 FLAT 4
28 011238-006 WASHER 3/8 SPLIT LOCK 16
29 011254-008 SCREW HHC 3/8-16 UNC X 1 16
30 0. GASKET 4
31 0. O-RING 2
32 011238-010 WACHER 5/8 SPLIT LOCK 16
33 102249-000 AXLE INDICATOR STRIP 6
34 065368-001 TACK FASTENER 24
