6-70 SB80 Work Platform - European
I
LLUSTRATED
P
ARTS
B
REAKDOWN
Section
6.1
S
IX
F
OOT
C
AGE
A
SSEMBLY
,
SB80
102037-100
ITEM PA RT NO. DESCRIPTION QTY.
1 102193-001 CAGE WELDMENT (6 FT.) 1
2 100478-000 LIFT-GATE WELDMENT 1
3 100481-000 ROLLER TUBE 2
4 011253-022 SCREW, HHC. 5/16-18 UNC X 2 3/4 2
5 011248-005 LOCKNUT, HEX. 5/16-18 UNC ESNA 2
6 100468-001 PANEL, DECAL MOUNT REF
7 026551-005 POP RIVET, 1/8” DIA. (3/16-1/4 GRIP) REF
8 102271-061 GRIP STRUT 11 3/4 X 1 1/2 X 68 1/2 3
9 026554-004 POP RIVET 1/4 .501-.625 GRIP 42
10 014996-004 WASHER 1/4 FLAT 38
11 102244-000 SILL GATE EURO 1
12 102245-000 WIRE CLOTH FLOOR 1
