5-2 SB80 Work Platform - European
S
CHEMATICS
Section
5.1
5.1 E
LECTRICAL
S
CHEMATIC
, SB80 - D
IESEL
Table 5-1: Electrical Schematic Legend: (102026-000)
DESIGNA
TION
NAME FUNCTION LOCATION
ALM Alarm, Tilt
Sounds when machine is out of
tilt parameters
Upper Control Box
ALT Alternator Power to engine and Battery Engine
BAT1 Battery Start Motor Engine Module
BAT2 Battery Auxillary Lowering Control Module
C1 Controller, Drive Control drive functions Upper Control Box
C2 Controller, Extend Control Boom Extend Functions Upper Control Box
C3
Controller, Lift,
Directional
Controll Lift and rotate Upper Control Box
C4 Throttle Controller Control Throttle Engine
CB1
Circuit Breaker,
Motor Start
Battery
Protecion for Motor start circuit Lower Control Box
CB2
Circuit Breaker,
Auxilliary Battery
Protection for Auxilliarty Motor
circuit
Lower Control Box
D1 Diode Power to R2 Lower Control Box
D2 Diode Protection Diode, R3 Lower Control Box
D3 Diode Protection Diode, R4 Lower Control Box
D4 Diode Power to R2
D5 Diode Lower Control Box
D6 Diode Lower Control Box
D7 Diode Protection Diode, R2 Lower Control Box
D8 Diode Protection Diode, R1 Lower Control Box
D9 Diode to Alternator Engine
Horn Horn Horn Sound Engine Module
ISO Isolator Charge Isolator Engine
Lamp1 LAMP TILT, Out of level Upper Control Box
Lamp2 LAMP Axles Extended Upper Control Box
Lamp3 LAMP Oil Pressure Low Upper Control Box
MOT1 Motor, Starter Start Engine Engine
MOT2 Motor Emergency Lowering Control Module
MTR1 Hour Meter Display Run Time Lower Control Box
MTR2 Oil Pressure Meter Display Oil Pressure Lower Control Box
MTR3 Temp Meter Display Engine Temp Lower Control Box
R1 Power Select Relay Main Power Relay Lower Control Box
R2 Power Relay
R3 Engine Start Relay Start Engine Lower Control Box
R4 Ignition Relay Power toEngine Ignition Lower Control Box
R5
Axle Extend/
Retract
Activate Axle Extend/Retract Lower Control Box
R6
Axle Extend/
Retract
Activate Axle Extend/Retract Lower Control Box
R7 Aux Pump Relay Power to Aux Pump Auxilliary Pump
R8 Glow Plug Relay Heat Glow Plugs Engine
R9 Engine Relay Allow Engine Operation Engine
REC Receiver Receive Signal From Transmitter Lower Control Box
SEN Tilt Sensor Tilt Sensor Lower Control Mod
SF4 SuperFlex 4 Controls Machine Functions Lower Control Mod
SOL1-2 Jib Solenoid Raise/Lower Jib
Interlock/Jib Valve
Block
SOL3-4 Cage Rotate Rotate Cage Left/Right
Interlock/Jib Valve
Block
SOL5 Solenoid Steer Left Lower Control Mod
SOL6 Solenoid Steer Right Lower Control Mod
SOL7 Solenoid Boom Down Lower Control Mod
SOL8 Solenoid Boom Up Lower Control Mod
SOL9 Solenoid Swing Left Lower Control Mod
SOL10 Solenoid Swing Right Lower Control Mod
SOL11 Solenoid Boom Retract Lower Control Mod
SOL12 Solenoid Boom Extend Lower Control Mod
SOL13 Solenoid Trim Down Lower Control Mod
SOL14 Solenoid Trim Up Lower Control Mod
SOL15 Solenoid Axle Retract Lower Control Mod
SOL16 Solenoid Axle Extend Lower Control Mod
SOL17
Dump Valve
Solenoid
Energize Dump Valve Lower Control Mod
SOL18
Boom Valve
Solenoid
Energize Boom Valve Lower Control Mod
SOL19
Generator
Solenoid
Allow Generator Operation Lower Control Mod
SOL20 Reverse Solenoid Drive in Reverse Main Pump
SOL21 Forward Solenoid Drive Forward Main Pump
SOL22 Solenoid Brake Valve Solenoid Engine Module
SOL23 Solenoid Axle Lock solenoid Engine Module
SOL24 Solenoid Shift Valve Solenoid Engine Module
SOL25 Solenoid Throttle Actuator
SW1 Glow Plug Switch Heat Glow Plugs Lower Control Box
SW2 Extend Switch Extend Boom Lower Control Box
SW3 Level Switch Level Platform Lower Control Box
SW4 Start Switch Start Engine Lower Control Box
SW5 Lift Switch Lift/Lower Boom Lower Control Box
SW6 Platform Switch Rotate Platform R/L Lower Control Box
SW7 Key Switch Key Switch Lower Control Box
SW8 Enable Drive Enable Lower Control Box
SW9 Jib Switch Raise/Lower Jib Lower Control Box
SW10 Emergency Stop Emergency Stop Lower Control Box
SW11 Auxilliary Power Lower Platform Lower Control Box
DESIGNA
TION
NAME FUNCTION LOCATION
SW12 Swing Rotate Platform Lower Control Box
SW13 Level Switch Level Platform Upper Control Box
SW14 Jib Switch Raise/Lower Jib Upper Control Box
SW15 Cage Switch Rotate Cage Upper Control Box
SW16 Auxilliary Power Lower Platform Upper Control Box
SW17 Glow Plug Switch Heat Glow Plugs Upper Control Box
SW18 Torque Switch High Torque Upper Control Box
SW19 Emergency Stop Emergency Stop Upper ControlBox
SW20 Horn Switch Activate Horn Upper Control Box
SW21 Axle Extend Switch Extend/Retract Axles Upper Control Box
SW22 Key Switch Enable Machine Operation Upper Control Box
SW23
Axle Pressure
Switch1
Indicate Axle Extend Axle
SW24
Axle Pressure
Switch
Indicate Axle Extend Axle
SW25
Oil Pressure
Switch
Indicate Oil Pressure Engine Module
SW26
Oil Pressure
Sending Unit
Signal to Control Box Engine
SW27 Temp Sending Unit Signal to Control Box Engine
SW28
Foot Interlock
Switch
Foot Interlock Platform Floor
SW29-32
Axle Interlock
Switch
Indicate Axle Extended Axles
SW33 Optional Lights Turn on Lights Upper Controller
SW34 Optional Generator Enable Generator Upper Controller
TIM Timing Card Cold Start Timing Advance Engine
TRA Transmitter Send Signals to Transmitter Upper Control Box
DESIGNA
TION
NAME FUNCTION LOCATION
