6-10 SB80 Work Platform - European
I
LLUSTRATED
P
ARTS
B
REAKDOWN
Section
6.1
F
INAL
A
SSEMBLY
, SB80
O
SCILLATING
A
XLE
, D
IESEL
102002-001
ITEM PA RT NO. DESCRIPTION QTY.
201 102455-000 PLUG, DEUTSCH P/N DTM06-12S 1
202 100338-016 SOCKET, DEUTSCH P/N 1062-20-0022 12
203 102455-002 WEDGE, DEUTSCH P/N WM-12S 1
204 102455-001 RECEPTACLE, DEUTSCH P/N DTM04-12P 1
205 100338-015 PIN, DEUTSCH P/N 0462-202-20141 12
206 102455-003 WEDGE, DEUTSCH P/N WM-12P 1
207 102021-000 CABLE ASSY, LWR BOX TO VALVE BLOCK 1
208 029488-099 WIRE CABLE, 16 AWG / 6 COND. FT 11
209 068760-000 PLUG, DEUTSCH P/N 1
210 068762-001 SOCKET, DEUTSCH P/N 8
211 068764-000 PLUG, SEALING 4
212 029490-099 WIRE CABLE, 16 AWG / 2 COND. FT 5
213 029931-003 CONN. FEM PUSH FULLY INS. 14-16 GA .25 15
214 029617-002 CONN. MALE PUSH F ULLY INS. 14-16 GA .25 7
215 029601-013 CONN, RING, 14-16 GA, #10 DIA. 4
216 029620-003 CONN. BUTT, 10-12 GA. 2
