Upright SB80 - Page 98

6-14 SB80 Work Platform - European
I
LLUSTRATED
P
ARTS
B
REAKDOWN
Section
6.1
B
ASIC
A
SSEMBLY
, SB80
O
SCILLATING
A
XLE
, D
IESEL
102005-000
ITEM PA RT NO. DESCRIPTION QTY.
1 102008-001 CHASSIS ASSEMBLY, (OSCILATING AXLE) 1
2 102010-000 TURRET ASSEMBLY 1
3 102009-000 BOOM ASSEMBLY 1
4 102263-000 COUNTERWEIGHT 1
5 102014-001 CONTROL MODULE ASSEMBLY (DSL) 1
6 102020-000 CONTROL CABLE ASSY 1
7 102012-000 ENGINE MODULE ASSEMBLY (DSL) 1
9 102337-000 LIFT CYLINDER 1
10 102336-000 MASTER CYLINDER 1
11 100473-002 PIN WELDMENT, 2.5 DIA. X 23 3/4 LG. 2
12 100473-003 PIN WELDMENT, 2.5 DIA. X 12” LG. 1
13 100472-012 PIN WELDMENT, 1.50 DIA. X 6 1/2 LG. 1
14 100575-015 PIN, 1.50 DIA. X 3 1/2 LG. 1
15 063559-010 SCREW, SHOULDER 5/16 X 3 1
16 011248-004 LOCKNUT, 1/4-20 UNC ESNA 1
17 011238-006 LOCKWASHER, 3/8” SPLIT RING 5
18 011254-007 SCREW, HHC. 3/8-16 UNC X 7/8 LG. 5
19 100472-010 PIN WELDMENT, 1.50 DIA. X 16 1/2 LG. 1
20 010092-011 THRUST WASHER 3
21 102218-000 CHASSIS COVER 2
22 011254-004 SCREW, 3/8-16 UNC X 1/2 LG. 14
23 011240-006 WASHER, 3/8” FLAT STEEL 14
24 011239-016 WASHER, 1” DIA. ASTM A-325 4
25 011732-024 SCREW, HHC. GR8 1-8 UNC X 3 4
26 011723-036 SCREW, HHC. GR8. 3/4-10 UNC X 4 1/2 24
27 011239-012 WASHER, 3/4” DIA. ASTM A-325 48
28 100198-000 SHIM, COUNTERWEIGHT 4
29 100380-000 PROXIMITY SWITCH 4
