V2 AYROS User Manual

ENGLISH
- 56 -
DISPLAYING DESCRIPTION SOLUTION
The display shows Err5 When a start command is given the gate
won’t open.
It means that the test of the safety edges
failed.
1. Make sure that the menu relative to the test of the
facets for cables (Co.tE) is configured correctly.
2. Make sure that the safety edges enabled by menu are
actually installed.
The display shows Err7 Encoder error Check the connection of the encoder
The display shows Err8 When executing a self-learning function the
control is refused.
It means that the setting of the control
unit is not compatible with the requested
function.
1. Check the Start inputs are enabled in standard mode
(Strt menu set on StAn).
2. Check the ADI interface is disabled
(i.Adi menu set to no).
The display shows Err9 It means that programming was locked by
means of the programming lock key CL1+
(code 161213).
To change the settings it is necessary to insert in the
connector of the ADI interface the same key used to
activate the programming lock, and unlock the device.
The display shows Er10 When a start command is given the gate
won’t open.
This means that the ADI module function
test failed.
1. Check the ADI module is correctly inserted
2. Check the ADI module is not damaged and working
properly
The display shows Er13 The self-diagnosis circuit has detected
a malfunction that prevents the safe
operation of the automation
Contact the V2 technical assistance service to send the
control unit for repair
The display shows Er14 The self-diagnosis circuit has detected an
error in the configuration parameter table
Enter the configuration menu, carefully check all the
parameters and correct any errors. If the error persists,
contact the V2 technical assistance service to send the
control unit for repair
