Vacon 100 flow User Manual

Assembly instances implemented by vacon® 100 family vacon • 69
24-hour support +358 (0)201 212 575 • Email: vacon@vacon.com
8
8.2.1.4 Assembly Instance 131
8.2.2 Vendor Input Instances
8.2.2.1
Assembly Instance 107
Table 72.
Instance Offset Octet 0 Octet +1 Octet +2 Octet +3
131
(length 40)
0
FBFixedControl-
Word (Low Octet)
FBFixedControl-
Word (High
Octet)
FBGeneralCon-
trolWord (Low
Octet)
FBGeneralCon-
trolWord (High
Octet)
4 Reserved Reserved
FBSpeedRef
(Low Octet)
FBSpeedRef
(High Octet)
8
FBProcessDataIn
1 Bits 7:0
FBProcessDataIn
1 Bits 15:8
FBProcessDataIn
1 Bits 23:16
FBProcessDataIn
1 Bits 31:24
12
FBProcessDataIn
2 Bits 7:0
FBProcessDataIn
2 Bits 15:8
FBProcessDataIn
2 Bits 23:16
FBProcessDataIn
2 Bits 31:24
16
FBProcessDataIn
3 Bits 7:0
FBProcessDataIn
3 Bits 15:8
FBProcessDataIn
3 Bits 23:16
FBProcessDataIn
3 Bits 31:24
20
FBProcessDataIn
4 Bits 7:0
FBProcessDataIn
4 Bits 15:8
FBProcessDataIn
4 Bits 23:16
FBProcessDataIn
4 Bits 31:24
24
FBProcessDataIn
5 Bits 7:0
FBProcessDataIn
5 Bits 15:8
FBProcessDataIn
5 Bits 23:16
FBProcessDataIn
5 Bits 31:24
28
FBProcessDataIn
6 Bits 7:0
FBProcessDataIn
6 Bits 15:8
FBProcessDataIn
6 Bits 23:16
FBProcessDataIn
6 Bits 31:24
32
FBProcessDataIn
7 Bits 7:0
FBProcessDataIn
7 Bits 15:8
FBProcessDataIn
7 Bits 23:16
FBProcessDataIn
7 Bits 31:24
36
FBProcessDataIn
8 Bits 7:0
FBProcessDataIn
8 Bits 15:8
FBProcessDataIn
8 Bits 23:16
FBProcessDataIn
8 Bits 31:24
Table 73.
Instance Octet Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
107
(length 8)
0
AtRef-
erence
Ref-
From-
Net
Ctrl-
From-
Net
Ready
Runnin
g2
(Rev)
Runnin
g1
(Fwd)
Warn-
ing
Faulted
1Drive State
2 FBSpeedActual (Low Octet) in %
3 FBSpeedActual (High Octet) in %
4 FBProcessDataOut1 (Low Octet)
5 FBProcessDataOut1 (High Octet)
6 FBProcessDataOut2 (Low Octet)
7 FBProcessDataOut2 (High Octet)

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
