Vacon 100 flow User Manual

8
vacon • 72 Assembly instances implemented by vacon® 100 family
Tel. +358 (0) 201 2121 • Fax +358 (0)201 212 205
8.2.2.4 Input Assembly Instance 137
8.3 Mapping of Standard Output Assemblies onto VACON® data
This section specifies how the data in the Standard Output Assemblies are mapped into VACON®
data.
8.3.1 FBGeneralControlWord and FBGeneralStatusWord
FBGeneralControlWord and FBGeneralStatusWord are purely application specific. Check the used
application’s manual for description of their content.
8.3.2 FBFixedControlWord
See Chapter 9 "APPENDIX 1 - VENDOR CONTROL AND STATUS WORD DESCRIPTIONS".
8.3.3 Start/Stop bit in VACON® FBFixedControlWord
If one of the “RunFwd” or “RunRev” bits in an Output Assembly has the value 1, the “Start/Stop” bit
0 in the VACON® FBFixedControlWord is set to 1. Otherwise the bit is set to 0.
If both the “RunFwd” and “RunRev” bits have the value 1, no changes are done to
FBFixedControlWord.
Table 76.
Instance Offset Octet 0 Octet +1 Octet +2 Octet +3
137
(length 40)
0
FBFixedStatus-
Word (Low
Octet)
FBFixedStatus-
Word (High
Octet)
FBGeneralSta-
tus-Word (Low
Octet)
FBGeneralSta-
tus-Word (High
Octet)
4 Reserved Reserved
FBSpeedActual
(Low Octet)
FBSpeedActual
(High Octet)
8
FBProcessData
Out1 Bits 7:0
FBProcessData
Out1 Bits 15:8
FBProcessData
Out1 Bits 23:16
FBProcessData
Out1 Bits 31:24
12
FBProcessData
Out2 Bits 7:0
FBProcessData
Out2 Bits 15:8
FBProcessData
Out2 Bits 23:16
FBProcessData
Out2 Bits 31:24
16
FBProcessData
Out3 Bits 7:0
FBProcessData
Out3 Bits 15:8
FBProcessData
Out3 Bits 23:16
FBProcessData
Out3 Bits 31:24
20
FBProcessData
Out4 Bits 7:0
FBProcessData
Out4 Bits 15:8
FBProcessData
Out4 Bits 23:16
FBProcessData
Out4 Bits 31:24
24
FBProcessData
Out5 Bits 7:0
FBProcessData
Out5 Bits 15:8
FBProcessData
Out5 Bits 23:16
FBProcessData
Out5 Bits 31:24
28
FBProcessData
Out6 Bits 7:0
FBProcessData
Out6 Bits 15:8
FBProcessData
Out6 Bits 23:16
FBProcessData
Out6 Bits 31:24
32
FBProcessData
Out7 Bits 7:0
FBProcessData
Out7 Bits 15:8
FBProcessData
Out7 Bits 23:16
FBProcessData
Out7 Bits 31:24
36
FBProcessData
Out8 Bits 7:0
FBProcessData
Out8 Bits 15:8
FBProcessData
Out8 Bits 23:16
FBProcessData
Out8 Bits 31:24

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
