Vacon 100 flow User Manual

Assembly instances implemented by vacon® 100 family vacon • 71
24-hour support +358 (0)201 212 575 • Email: vacon@vacon.com
8
8.2.2.3 Assembly Instance 127
The contents of the assembly are otherwise identical to the input assembly 117, except that the
second octet of the assembly is the high octet of FBGeneralStatusWord instead of
FBFixedStatusWord.
Table 75.
Instance Octet Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
127
(length 20)
0FBFixedStatusWord (Low Octet)
1 FBGeneralStatusWord (High Octet)
2 FBSpeedActual (Low Octet) in %
3 FBSpeedActual (High Octet) in %
4 FBProcessDataOut1 (Low Octet)
5 FBProcessDataOut1 (High Octet)
6 FBProcessDataOut2 (Low Octet)
7 FBProcessDataOut2 (High Octet)
8 FBProcessDataOut3 (Low Octet)
9 FBProcessDataOut3 (High Octet)
10 FBProcessDataOut4 (Low Octet)
11 FBProcessDataOut4 (High Octet)
12 FBProcessDataOut5 (Low Octet)
13 FBProcessDataOut5 (High Octet)
14 FBProcessDataOut6 (Low Octet)
15 FBProcessDataOut6 (High Octet)
16 FBProcessDataOut7 (Low Octet)
17 FBProcessDataOut7 (High Octet)
18 FBProcessDataOut8 (Low Octet)
19 FBProcessDataOut8 (High Octet)

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
