7. COMMON INDUSTRIAL OBJECTS IMPLEMENTED BY VACON®
100 FAMILY
7.1 CIP Common Required Objects
7.1.1 Identity Object, Class 0x01
The Identity Object provides identification of and general information about the device.
Table 11. Identity Object
Class name Identity Object
Class identifier 1
Class
Attributes
Id Access rule Name Datatype Description
1 Get Revision UINT Class revision (1)
2GetMax InstanceUINT
Maximum instance num-
ber (1)
3Get
Number of
Instances
UINT
Number of object
instances(1)
Class Ser-
vices
Id Name Description
1 Get_Attributes_All Get all attributes
14
d
0E
h
Get_Attribute_Single Get single attribute
Instance
Attributes
Id Access rule Name Datatype Description
1 Get Vendor ID UINT Vendor identification
2 Get Device Type UINT General type of product
3 Get Product Code UINT Product identification
4 Get Revision STRUCT of
Revision of the item the
Identity Object repre-
sents
Major Revision USINT
Minor Revision USINT
5StatusWORD
Summary status of
device
6 Serial number UDINT
Serial number of the
device
7Product Name
SHORT
STRING
Human readable identifi-
cation
Instance
Services
Id Name Description
1 Get_Attributes_All Get all attributes
5 Reset Only reset type 0
14
d
0E
h
Get_Attribute_Single Get single attribute

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
