Vacon 100 flow User Manual

EtherNet/IP vacon • 24
24-hour support +358 (0)201 212 575 • Email: vacon@vacon.com
6
Figure 7. EtherNet/IP timeout logic with explicit connection
Communicating
Received packet within
“TCP Inativity” time?
Has user written
process data over this
connection
Communication
timeout zero?
Has additional
timeout elapsed?
Check
No
No
No
No
Yes
Yes
Yes
FAULT!
Offline
Cable disconnected
Connection closed
11721_uk

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
