7.4.4 Advancement on Drive State Conditions
Figure 7-2 shows how the Seq Count parameter is bit-packed with drive state conditions when the
state duration bits are programmed to 1010 and 1011. If the AND (1010) configuration is selected,
then all bits set in the count parameter must have the corresponding drive state occur for
advancement to the next state. If the OR (1011) configuration is selected, then any bits in the count
parameter must have the corresponding drive state occur for advancement to the next step.
Figure 7-2: Seq Count Parameter’s Drive State Bit-Packed Definition
Running FWD
Running REV
At Speed
Zero Speed
Freq Limit Active
Freq Hyst Active
Current Limit Active
DB Active
High Temp Active
Thres 1 Active
Thres 2 Active
Timer 1 Active
Timer 2 Active
Reminder 1 Active
Reminder 2 Active
Reminder 3 Active
Bit number
1514131211109876543210
0000000000000000
