Unpacking the OneLINK HDMI Camera Extension
Make sure you received all the items you expected. Here are the packing lists for the OneLINK HDMI kits.
Every OneLINK device ships with a power supply and at least one AC cord set. The last three digits of the
kit part number contain the regional code that specifies which cord set(s). For most OneLINK kits, the part
numbers follow this convention:
n Kits with part numbers ending in -000 include one AC cord set for North America.
n Kits with part numbers ending in -001 include two AC cord sets, one for Europe and one for the UK.
n Kits with part numbers ending in -009 include one AC cord set for Australia and New Zealand.
Exceptions are noted case by case in the following packing lists.
OneLINK HDMI for HDBaseT Cameras
OneLINK HDMI Camera Extension for Vaddio HDBaseT Cameras, 999-1105-043/143/943
Camera not included.
n OneLINK HDMI Receiver, 998-1105-043
n Power supply, 48 VDC/1.36 A, with AC cord set(s)
o
Kit 999-1105-043 includes one AC cord set for North
America.
o
Kit 999-1105-143 includes two AC cord sets, one for
Europe and one for the UK.
o
Kit 999-1105-943 includes one AC cord set for Australia and New Zealand.
n EZCamera RS-232 control adapter (998-1001-232)
n Quick-Start Guide 411-0019-01
OneLINK HDMI For HDBaseT Cameras Used with Codecs
OneLINK HDMI for Vaddio HDBaseT Cameras with Polycom Codecs, 999-9545-000/001/009
Camera and codec not included.
n OneLINK HDMI Receiver
n Power supply, 48 VDC/1.36 A, with AC cord set(s)
n 3-position Euro-style connector, 5 mm
n Fan-out cable, codec side, 2 ft. (0.6 m)
n EZCamera RS-232 control adapter 998-1001-232
n Quick-Start Guide 411-0019-01
3
Integrator's Complete Guide to the OneLINK HDMI Camera Extension
