Specifications
Capabilities
Video output HDMI 1.4b – matches camera
resolution, up to 2160p/29.97
IP Streaming Passes the stream from the
camera, if enabled
Control Features Web interface for configuration via browser
Telnet API for third-party external control
Ethernet and RS-232 control pass-through to camera
IR forwarding from camera
Maximum cable
length
328 ft (100m) Cat-5e cable; shielded Cat-6 recommended where EMI/RF interference is
an issue
Power, Physical, and Environmental
Input Power 48 VDC, 1.36 A Output Power to
Camera
12 VDC, 3.0 A
Height 1.72 in. (4.4 cm)/1U Width 8.38 in. (21.3 cm)
Depth 6.0 in. (15.2 cm) Weight 1.55 lb. (0.7 kg)
Operating/Storage
Temperature
32° to 104° F (0° to 40° C)
Operating/Storage
Humidity
20% to 80% RH, non-
condensing
64
Integrator's Complete Guide to the OneLINK HDMI Camera Extension
