Chapter 6 _______________________________________________________________ Maintenance
VAISALA _______________________________________________________________________ 141
10. Check repair success.
- Repeat the failed test steps.
- Proceed with trouble shooting and re-install the original board in
case this repair step was not successful.
11. Close central compartment cover carefully after successful repair.
- Pay attention to the placement of the compartment cover gasket
ring. Fix the four cover screws firmly and hand-tight.
Figure 44 VS Bottom View, Central Compartment Cover
Screws
Cover Screws (4 pcs.)
