945
Model Code Page
61. Steering system
6250--8950 610 17
1. 10. 1999
Reverse drive controls (Tw inTrac) on HiTech models
1
5
6
7
8
9
2
3
4
6080---169
10
1. Rear steering wheel
2. Clutch pedal
3. Brake pedal
4. Gas pedal
5. Shuttle lever/parking brake lever
6. Delta Power Shift pre---programming button for driving
direction change
7. Lever to adjust steering wheel distance
8. Delta Power Shift switch, three positions
9. Stop (red pilot light, does not flash)
If the stop lamp comes on, the tractor
and the engine must be stopped
immediately. Only in emergency the
driving can be continued little while.
10. Display unit for driving direction change,
for DPS etc.
